Установка Asterisk 11 + FreePBX на CentOS 6.5


Пошаговая инструкция для установки программной PBX Asterisk 11.x и панели управления FreePBX на CentOS 6.5

Условия:

Система CentOS установлена и имеет доступ в интернет.

Подготовка

  1. # yum -y update
  2. Выключить SELinux:
    # vi /etc/selinux/config
  3. # reboot
  4. Дополнительные репозитарии:
    # rpm -Uvh http://pkgs.repoforge.org/rpmforge-release/rpmforge-release-0.5.3-1.el6.rf.x86_64.rpm
    # rpm -Uvh http://dl.fedoraproject.org/pub/epel/6/x86_64/epel-release-6-8.noarch.rpm

  5. # yum -y install mc make gcc kernel-devel gcc-c++ ncurses-devel httpd mysql-server mysql mysql-devel php iksemel iksemel-devel crypto-utils openssl-devel gmime gmime-devel spandsp spandsp-devel openldap openldap-devel popt-devel libresample libresample-devel speex speex-devel libcurl-devel speex-tools svn sqlite-devel mod_ssl php-mysql php-pear-MDB2-Driver-mysqli php-mbstring php-gd php-mcrypt libxml2-devel lame bison audiofile-devel sox php-pear-DB php-posix

  6. # cd /root
  7. # wget http://downloads.asterisk.org/pub/telephony/asterisk/asterisk-11-current.tar.gz
    # tar -zxf asterisk-11-current.tar.gz
  8. # wget http://downloads.asterisk.org/pub/telephony/libpri/libpri-current.tar.gz
    # tar -zxf libpri-current.tar.gzwget http://downloads.asterisk.org/pub/telephony/dahdi-linux-complete/dahdi-linux-complete-current.tar.gz
    # tar -zxf dahdi-linux-complete-current.tar.gz

 Установка  DAHDI, libPRI и Asterisk

  1. # cd dahdi-linux-complete-2.9.0+2.9.0.1
    #make all
    #make install
    #make config
  2. # cd libpri-*
    # make
    # make install

  3. # cd asterisk-11.7.0
    # ./configure --prefix=/usr --exec-prefix=/usr --with-crypto --with-dahdi --with-iconv -with-libcurl --with-gmime --with-iksemel --with-mysqlclient --disable-xmldoc --with-pri --with-spandsp --with-ldap --with-libcurl --with-popt --with-resample --with-speex
    # make menuselect
    # contrib/scripts/get_mp3_source.sh
    # make
    # make install
    # make samples

  4. # ln -s /usr/lib/libasteriskssl.so.1 /usr/lib64/libasteriskssl.so.1
    # ln -s /usr/lib/libpri.so.1.4 /usr/lib64/libpri.so.1.4
    # cat contrib/init.d/rc.redhat.asterisk | sed 's/__ASTERISK_SBIN_DIR__/\/usr\/sbin/' > /etc/init.d/asterisk
    # chkconfig --add asterisk
    # cp -rf configs/* /etc/asterisk/

  5. # service dahdi start
    # service asterisk start


Установка FreePBX

  1.  # wget “http://downloads.sourceforge.net/project/phpmyadmin/phpMyAdmin/3.5.5/phpMyAdmin-3.5.5-all-languages.tar.gz?r=http%3A%2F%2Fsourceforge.net%2Fprojects%2Fphpmyadmin%2Ffiles%2FphpMyAdmin%2F3.5.5%2FphpMyAdmin-3.5.5-all-languages.tar.gz%2Fdownload&ts=1358931580&use_mirror=ignum”
    # tar -zxf phpMyAdmin-3.5.5-all-languages.tar.gz -C /var/www/
  2. в /etc/hosts добавить:
    [IP PBX] pbx-mysql.example.com
    [IP PBX] pbx.example.com
  3. в конфиг /etc/httpd/httpd.conf:
    NameVirtualHost *:443
  4. в конфиг /etc/httpd/conf.d/ssl.conf добавить:
    DocumentRoot "/var/www/phpmyadmin"
    ServerName pbx-mysql.example.com:443
    ErrorLog logs/ssl_phpmyadmin_error_log
    TransferLog logs/ssl_phpmyadmin_access_log
    LogLevel warn
    SSLEngine on

    SSLProtocol all -SSLv2
    SSLCipherSuite ALL:!ADH:!EXPORT:!SSLv2:RC4+RSA:+HIGH:+MEDIUM:+LOW
    SSLCertificateFile /etc/pki/tls/certs/localhost.crt
    SSLCertificateKeyFile /etc/pki/tls/private/localhost.key

    SSLOptions +StdEnvVars

    <Directory "/var/www/cgi-bin">
    SSLOptions +StdEnvVars

    SetEnvIf User-Agent ".*MSIE.*" \
    nokeepalive ssl-unclean-shutdown \
    downgrade-1.0 force-response-1.0

    CustomLog logs/ssl_phpmyadmin_request_log \
    "%t %h %{SSL_PROTOCOL}x %{SSL_CIPHER}x \"%r\" %b"

    <Directory "/var/www/phpmyadmin">
    Order allow,deny
    Allow from [Admin IP]

    DocumentRoot "/var/www/html"
    ServerName pbx.example.com:443
    ErrorLog logs/ssl_html_error_log
    TransferLog logs/ssl_html_access_log
    LogLevel warn
    SSLEngine on

    SSLProtocol all -SSLv2
    SSLCipherSuite ALL:!ADH:!EXPORT:!SSLv2:RC4+RSA:+HIGH:+MEDIUM:+LOW
    SSLCertificateFile /etc/pki/tls/certs/localhost.crt
    SSLCertificateKeyFile /etc/pki/tls/private/localhost.key

    SSLOptions +StdEnvVars

    <Directory "/var/www/cgi-bin">
    SSLOptions +StdEnvVars

    SetEnvIf User-Agent ".*MSIE.*" \
    nokeepalive ssl-unclean-shutdown \
    downgrade-1.0 force-response-1.0

    CustomLog logs/ssl_html_request_log \
    "%t %h %{SSL_PROTOCOL}x %{SSL_CIPHER}x \"%r\" %b"

    <Directory "/var/www/html">
    Order allow,deny
    Allow from [Admin IP]

  5. # cd /var/www/
    # ln -s phpMyAdmin-3.5.5-all-languages phpmyadmin
    # service httpd restart
    # chkconfig --levels 345 mysqld on
    # chkconfig --levels 345 httpd on
    # service mysqld start
    # /usr/bin/mysql_secure_installation


    Установить пароль root для MySQL

  6. # cd /root
    # wget http://mirror.freepbx.org/freepbx-2.11.0.43.tgz
    # tar -zxf freepbx-2.11.0.tar.gz -C /usr/src
    # cd /usr/src/freepbx-2.11.0
  7. Отредактировать php.ini:
    # vi /etc/php.ini (или /etc/php4/apache2/php.ini)
    upload_max_filesize=20M

  8. # mysqladmin create asteriskcdrdb -p
    # mysql -p asteriskcdrdb < SQL/cdr_mysql_table.sql
    # mysqladmin create asterisk -p
    # mysql -p asterisk < SQL/newinstall.sql
    # mysql -p
    mysql> GRANT ALL PRIVILEGES ON asteriskcdrdb.* TO asteriskuser@localhost IDENTIFIED BY '[ваш пароль]';
    mysql> GRANT ALL PRIVILEGES ON asterisk.* TO asteriskuser@localhost IDENTIFIED BY '[ваш пароль]';
    mysql> flush privileges;

  9. # groupadd asterisk
    # useradd -c "asterisk PBX" -d /var/lib/asterisk -s /sbin/nologin -g asterisk asterisk
  10. Отредактировать:
    # vi /etc/httpd/conf/httpd.conf (или /etc/apache2/apache2.conf):
    User asterisk
    Group asterisk

  11. # chown asterisk /var/lib/php/session
  12. # ./install_amp
  13. Заменить в базе asterisk в таблице freepbx_settings пароль для астериск манагера:
    # mysql -p
    mysql> UPDATE `asterisk`.`freepbx_settings` SET `value` = '[ваш пароль 2]' WHERE `freepbx_settings`.`keyword` = 'AMPMGRPASS';
  14. # chown asterisk /etc/modprobe.d/dahdi.conf
  15. # rm /etc/asterisk/ccss.conf /etc/asterisk/logger.conf /etc/asterisk/iax.conf /etc/asterisk/extensions.conf /etc/asterisk/sip_notify.conf /etc/asterisk/features.conf /etc/asterisk/sip.conf
  16. Изменить что-нить в freepbx нажать аплай (дефолтный логин/пароль — admin/admin)
  17. Поменять дефолтный пароль

Допольнительные установки:

  1.  # yum -y install bind bind-utils mailx ntp
    # chkconfig --add named
    # chkconfig --add ntpdate
    # service ntpdate start
    # service named start
    # echo “nameserver 127.0.0.1” > /etc/resolv.conf
    # echo “nameserver 8.8.8.8” >> /etc/resolv.conf
  2. # yum -y install xinetd tftp-server
    # vi /etc/xinetd.d/tftp
    -s /tftp -c
    # mkdir /tftp &&
    # chown nobody /tftp
    # vi /etc/sysconfig/iptables
    # service xinetd start

  3. Добваить в iptables:
     -A INPUT -m udp -p udp -d [IP PBX]/32 --dport 5060 -m hashlimit --hashlimit 10/m --hashlimit-burst 10 --hashlimit-mode srcip,dstip,dstport --hashlimit-htable-expire 180 --hashlimit-name SIP -j ACCEPT
